Your new command center for Eurorack output and monitoring.
Get precise control over what goes out and what you hear. The OUTMIX is designed to be the clear, essential final stage for your patches.
SPECIFICATIONS
- Stereo output or dual mono mixer functionality.
- Dedicated Cue Input lets you preview signals discreetly – perfect for performance.
- Flexible Headphone out with switchable source (Pre-Level, Master, Cue)
- Fully balanced output (optional on rear panel)
- Horizontal Pitch: 4 HP
- Depth: 35 mm deep
- Current Draw: 39mA +12v; 27mA -12v
